    Molex 4 Pin To 15 Pin SATA Hard Drive Power Cable Female To Male Length 500mm

    Ask Lasest Price
    Brand Name : SHUANG YI
    Model Number : SY-B160033-0
    Certification : ISO9001/ISO14001/SGS/UL/RoHS/Reach
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 100000 Pieces Per Month
    Delivery Time : 7~10 Work days
    • Product Details
    • Company Profile

    Molex 4 Pin To 15 Pin SATA Hard Drive Power Cable Female To Male Length 500mm

    Molex 4 Pin To 15 Pin SATA Hard Drive Power Cable Female To Male Length 500mm


    SATA power cable: 4-Pin housing to 15-Pin; supply electricity for hard disk

    The P/N 1959 series cable is a Serial ATA power to 4-pin molex cable for new high-speed SATA disk drives.

    It is designed to convert a standard 4-pin molex connector, as used for standard IDE hard drives and CD-ROMs, into the new SATA power connector.

    The new Serial ATA interface is designed to replace the older parallel-style IDE. Serial ATA offers higher speeds (150 MB/sec) and longer-length cables without the mess of wide ribbons.


    Specifications:

    1. Connector A: 15pin SATA Female connector
    2. Connector B: 4 pin Male Molex connector
    3. Material: PBT / LCP/PVC/TPE/PU/TPU
    4. Terminal: Phosphor Bronze
    5. Cable: 26awg, 28awg, 30awg
    6. Transfer rates:Up to 1.5 gbps (can be customized 3 gbps)
    7. Conductor: All copre/Copper ,Tinned copper or optional
    8. OD&Length: Customized
    9. Color: Any color are available
    10. Shielding: Braid

    11. High quality 4 pin Molex connecter to 15PIN Serial ATA Power Splitter Cable

    12. Use your high speed Serial ATA (SATA) hard drives with the original 4 pin cord Connect 1x4 pin Molex power connector to 15 PIN Serial ATA power connecters

    13. Great for users with limited numbers of SATA power cables and multiple SATA drives, or for a power supply that does not provide one.
    14. Transfer a 4-Pin power connector to SATA Female power connectors
    15. Simple connect the 4pin male connector to a 4pin female connector which is supplied by your computer power adapter
    16. Compliant with Serial ATA 1.0 Standards
    17. Performance:support computor,pc,and so on device
    18. Easy to install and easy to use

    Electrical:

    1. Hi-Pot Test: DC300V
    2. Insulation Resistance: 10M Ohms (Min)
    3. Contactor Resistance: 1 Ohms (Max)
    4. 100% Open Short and Miss Wire Test

    Application:

    Suit for 3.5” SATA Hard Disk and 3.5” SATA CD-ROM, DVD-ROM, DVD-R/W, CD-R/W Computer, DVD, Torage, HDD, Hard disk, CD of the firmware, CDRWs,DVD and so on.
